MEGA500

MEGA500 is an expandable Megamide braided sleeve valued for its resistance to high temperatures. It has a constant working temperature of -40°C to + 170°C, withstands short-term peaks of 230°C and a melting point of 260°C. It is available in black and grey in sizes up to 70mm supplied diameter as standard. It can be cut as required.

This braided jacket is ideal for rigorous mechanical applications where resistance to heat and self-extinguishing characteristics are also a consideration. Exposure of Megamide to a naked flame under test conditions shows that it conforms to current aeronautic standards for electric cables. It is often used in scientific, electronic, electrical and telephonic equipment as well as in television, aviation and marine industries. MEGA500 is available in several colours as well as the standard grey and black. This particular 0.25mm monofilament grade is especially recommended for aviation cable and for electrical cabinet cabling. Other grades of Megamide are also available on enquiry.

Technical Data

  • Operating Temperature -40°C-+170°C
  • Flame Retardant: Self-extinguishing
  • Colours: Black, Other colours available upon request
  • Sizes: 3 → 70
  • Packing: Reels, mini-reels, mini-packs, cut to length, cut sleeves
  • Approvals: Ul approved, RoHS Compliant
  • Applications / Industries:

Properties Typical Values Test Methods
General
Operating Temperature -40°C - + 170°C
Short-term peak temperature 230°C
Melt temperature 255°C
Monofilament thickness 0.25mm
Physical
Specific gravity 1.13kg/dm³ DIN 53479
Water absorption at 23°C, 50% immersion 2.8%, full immersion 8.5% DIN 53714, 53495
Thermal
Flammability Pass UL94 V2
Chemical
Chemical resistance Unaffected by most chemicals
Oxygen Index 27% ASMT D 2863
Toxicity Halogen & phosphorus free
Opacity Low smoke density
